Mosconin huippu luokan AB-luokan 4-kanavainen DSP pääte. Tekniset tiedot: 4 Channel amplifier with DSP inside Black finishing Power Rating: 130 Watt per channel @ 4 Ohm Sn Ratio: > 67 dBA (ref: 1 Watt into 4 Ohm) ONE 130.4 DSP INSIDE Incl. DSP 4to6 on board Only one software, always updated. 4 presets instead of 2. Low level DSP processed output (as the CH5-6 in the D2-100.4DSP). It works with RCD and RCD-mini. Target powers: 130 Watt per channel @ 4 Ohm 175 Watt per channel @ 2 Ohm 350 Watt BTL mode @ 4 Ohm Input sensitivity: (Power rating ref) 0.28 V ÷ 5.7 V (LL) / 0.8 V ÷ 16 V (HL) DSP ominaisuudet: Features & Xover functions High Low Adapter Autosense power-on (High Level only, SE or BTL mode) Hand-free, Navigator, AUX inputs Auto-Fading between inputs Signal Mix capability USB cable for PC connection BT wireless module for PC connection (optional) GUI (Windows XP,VISTA 32/64bit and 7 32/64bit) Available hardware presets: two External memory for additional presets (optional) 30 bands parametric equalizer Implemented filters type: all standard filters available HP frequency range for each channel Hz: 10 ÷ 20000 LP frequency range for each channel Hz: 10 ÷ 20000 HP and LP filter slope for each cell: dB/Oct 6 to 24 (up to 48 if cascaded) Band pass allowed: yes Variable “Q”: 0.25 ÷ 40 Time delay ms: 0 ÷ 15 (0,02 steps) Phase inversion for each channel: 0 / 180° Gain level for each channel dB: -115.5 ÷ 6 Remote Volume Control (optional) Size: 310x200x50 mm Weight: 2,7 Kg
